Midi
| Genuin BKS | Tempesta BKS | Midi | Mini | |
|---|---|---|---|---|
| MaterialMaterialMateriale | Birch plywoodBirke MultiplexMultistrato di betulla | MDF | MDF | MDF |
| ThicknessMaterialdickeSpessore | 18mm / 0,75" | 19mm / 0,75" | 19mm / 0,75" | 19mm / 0,75" |
| Internal BracingVerstrebungIrrigidimento | Structural bracing interactionStrukturelle interaktionInterazione strutturale | No | No | No |
| Cross over chamberKammer für FrequenzweicheVolume separato per filtro | No | No | No | No |
| Frequency rangeFrequenzgangRisposta in frequenza | 50Hz - 20kHz ± 2dB | 50Hz - 20kHz ± 2dB | 60Hz - 20kHz ± 2dB | 60Hz - 20kHz ± 2dB |
| Bass CabinetBass GehäuseCabinet dei bassi | Harmonic Bass Reflex | Bass reflex | Bass reflex | Bass reflex |
| PortingBass ReflexCanale | FloorZum BodenA pavimento | RearNach hintenPosteriore | RearNach hintenPosteriore | RearNach hintenPosteriore |
| WooferTiefmitteltönerWoofer: | 200mm / 8" - 250mm / 10" | 170mm / 6,5" | 130mm / 5" | 100mm / 4" |
| MaterialMaterialMateriale | Paper P2F® SandwichPapier P2F® SandwichCarta Sandwich P2F® | Peek-Carbon P2C® Sandwich | Peek-Carbon P2C® Sandwich | PaperPapierCarta |
| Cross over frequencyÜbergangsfrequenzFrequenza di taglio | 1200 Hz | 1800 Hz | 3000 Hz | 6000 Hz |
| MidhighMittelhochtönerMedioalti: | Compression driverKompressionstreiberDriver a compressione | Compression driverKompressionstreiberDriver a compressione | DomeKalotteCalotta | DomeKalotteCalotta |
| Horn ThroatHornDiametro tromba | 1" | 1" | - | - |
| Membrane dimensionsMembranendimensionDimensione Membrana | 44mm / 1,75" | 35mm / 1,4" | 28mm / 1,1" | 25mm / 1" |
| MaterialMaterialMateriale | Mylar | Mylar | SilkSeideSeta | SilkSeideSeta |
| Max power inputBelastbarkeitPotenza massima (RMS) | 150 W RMS | 100 W RMS | 80 W RMS | 60 W RMS |
| EfficiencyWirkungsgradEfficienza | 90dB | 90dB | 88 dB | 88dB |
| ImpedanceImpedanzImpedenza | 8 Ohm | 8 Ohm | 8 Ohm | 6 Ohm |
| Impedance linearizationImpedanzlinearisierungLinearizzazione d'impedenza | YesJaSi | No | No | No |
| TerminalAnschlussfeldTerminali | Bi-Amping | Single-Wiring | Single-Wiring | Single-Wiring |
| MaterialMaterialMateriale | Gold plated tellurium copperVergoldetes tellurium KupferRame tellurio placcato oro | Gold plated brassVergoldetes MessingOttone placcato oro | Gold plated brassVergoldetes MessingOttone placcato oro | Single-Wiring gold platedSingle-Wiring vergoldetSingle-Wiring placcato oro |
| FeetsFüßePiedi | Adjustable SpykesRegelbare SpykesSpykes regolabili | No | No | No |
| DimensionsMaßenDimensioni [mm] | 8" - 600 x 290 x 375 mm 10" - 680 x 340 x 430 mm | 480 x 220 x 320 mm 19 x 8,5 x 12,5 in | 338 x 290 x 162 mm | 280 x140 x270 mm 11 x 5,5 x 10,5 in |
| WeightGewichtPeso | 10,5 kg | 7 kg | 5 kg | |
| Packaging dimensionsVerpackungsmaßenDimensioni imballate | 69 x 43 x 36 cm | 48 x 48 x 44 cm | 45 x 45 x 42 cm | |
| Loudspeakers per cartonLautsprecher per KartonPezzi pro cartone | 2 | 2 | 2 | 2 |
| Packaging weightVerpackungsgewichtPeso imballate | 17 kg | 12 kg | ||
| Center LoudspeakersCenter LautsprecherDiffusori centrali: | Center 20 | Center 17 | - | - |
| Center 17 | Center 15 | - | - | |
| Standard VeneersStandard FurniereFiniture standard: | Walnut, Dark WalnutWalnuss, Dunkles WalnussNoce, Noce Scuro | |||
| Special VeneersSpezial FurniereFiniture speciali: | Black Walnut, on demandSchwarz Walnuss, auf AnfrageNoce Nero e su richiesta | |||
| Premium VeneersPremium FurniereFiniture premium: | On demandAuf AnfrageSu richiesta | |||
